SiteMaster Elevation
Photographic Facade Survey

SiteMaster Elevation - surveying to precise exterior views
Save Time and Money - Now you can produce Elevational Drawings from Photographs

Photographic Facade Survey

SiteMaster Elevation is an independent add-on for SiteMaster. You can benefit from photogrammetric procedures by determining detailed measurements from freehand digital photographs or scanned images.

SiteMaster Elevation requires only one rectangle with two known side lengths for calibrating an image plan. The software lets you measure and draw a building in 2D with added height information on floors, openings etc.

It saves the exact measurement results by redrawing the image with points, lines, rectangles, polylines, arcs and circles. SiteMaster Elevation transfers drawing elements with state-of-the-art technology to your CAD system, e.g. or SiteMaster Building. After completing your measurements you can generate a report list of all measurements and areas. The results can be exported in excel lists.

Processing digital photographs of the building’s facade in SiteMaster Elevations allows you to enhance your project into a full 3D plan with precise exterior views. You can exchange drawing files between SiteMaster Elevation, SiteMaster (and other solutions) using the .FLX (PowerCAD) and .DXF file formats.

Download a FREE trial of Sitemaster Elevations software

Sitemaster Elevations screenshots

Sitemaster Building

Sitemaster Building software the Professionals choice - The mobile solution for Professional Building Surveys and Fast CAD Drawings carried out On Site in Real Time. Draw fast and accurate walls (as single or double line), windows, doors and symbols rectangular and circular columns, recesses, ,chimneys, ducts, room areas, volumes, perimeters and much more.

For professional building surveys

The extensive features of SiteMaster Building are especially interesting for users that need to create and deliver professional Fast CAD drawings.

The layer management supports the combination of several floor plans in one single file. Heights of rooms, openings and symbols can be recorded and exported. Lasered distances are recorded in the background and saved on an extra layer for proofing purposes.

Survey Methodology
Surveys are conducted using a hand-held Laser Measure (Leica Disto A6, Leica Disto D8, Leica Disto D3aBT or a Hilti PD38) coupled via ‘Bluetooth’ technology to a hand-held microcomputer a Viliv X70 tablet.

This approach, which produces the CAD drawing during the survey process, allows us to establish and accurately check all building dimensions while on site. Significant improvements in survey quality are gained using this equipment when compared with traditional survey methods.

Check measurements are taken to ensure accuracy Gone are the days where two men would hold a sagging tape measure from one end of the room to the other, that old method is history! There are NO more return visits to site due to blunt pencils and inaccurate paper documentation, NO guesswork, NO wrong data documentation NO sagging tape measures.

Click here to book a FREE demonstration

Download a FREE trial of Sitemaster Building

Sitemaster Building screenshots
